Aqara Valve Controller T1

Technical Specifications

• Short Description : Valve Controller T1 (Model No: VC-X01D)

Compliance

• Valve Types : lever handle, butterfly handle

Sensors

• Type : Valve Controller

Transmission Method

• ZigBee

Battery

• Battery Included : Yes

• Battery Quantity : 4

• Battery Type : AA

Environment

• Operating Temperature : -10°C to 50°C

• Operating Humidity : 0% to 95%

Difference

• Exterior Color : White

• Remote Control Functions :

  • Torque: ≤ 3.6 N m

  • Valve Pressure: 1.6 MPa

  • Compatible Pipe Diameters: DN15, DN20, DN25

  • Closing Time: 5–20 seconds

• Included Accessories : Quick Start Guide

Device Dimensions & Weight

• Width : 72 mm.

• Height : 93 mm.

• Depth : 84 mm.

Warranty

• Returnable product : Yes

• Warranty Period : 24 months

• Validation Criteria : Serial number

Material Characteristics

• Packaging Length : 130 mm.

• Packaging Width : 105 mm.

• Packaging Height : 130 mm.

• Packaging Weight (Gross) : 0.77 kg

• Net Package Weight : 0.431 kg

• Packed Pieces : 1

• Box Length : 563 mm.

• Box Width : 295 mm.

• Box Height : 160 mm.

• Gross Package Weight : 8.27 kg

• Retail Box Net Weight : 0.431 kg

• Net Weight of Plastic Packaging : 0 kg

• Packages in a Package : 10

• Packaging Type : Box

Other Details

• EAN code : 6975833356195
